MikroTik · RouterBOARD
L11UG-5HaxD
SKU: L11UG-5HaxD
$79.00Call for Availability
Manufacturer suggested price: $79.00
Build your own custom outdoor 5 GHz CPE or AP with Wi-Fi 6, dual-core ARM CPU, PoE-in, Gigabit Ethernet and RouterOS v7! MMCX connectors allow creating versatile omnidirectional access points and powerful point-to-point links.
- wifi-qcom
Need help with this product?
Call us at 888-NET-FIX-8
Specifications
Specifications
- Product code
- L11UG-5HaxD
- Architecture
- ARM 32bit
- CPU
- IPQ-5010
- CPU core count
- 2
- CPU nominal frequency
- 800 MHz
- CPU Threads count
- 2
- RouterOS license
- 4
- Operating System
- RouterOS v7
- Size of RAM
- 256 MB
- Storage size
- 128 MB
- Storage type
- NAND
- MTBF
- Approximately 100'000 hours at 25C
- Tested ambient temperature
- -40°C to 70°C
Powering
- Number of DC inputs
- 2 (DC jack, PoE-IN)
- DC jack input Voltage
- 12-28 V
- Max power consumption
- 15 W
- Max power consumption without attachments
- 6 W
- PoE in
- Passive PoE
- Cooling type
- Passive
- PoE in input Voltage
- 18-28 V
Wireless specifications
- Wireless 5 GHz Max data rate
- 2400 Mbit/s
- Wireless 5 GHz Number of chains
- 2
- Wireless 5 GHz standards
- 802.11a/n/ac/ax
- Wireless 5 GHz chip model
- QCN-6102
- Wireless 5 GHz generation
- Wi-Fi 6
Ethernet
- 10/100/1000 Ethernet ports
- 1
Peripherals
- Number of USB ports
- 1
- USB Power Reset
- Yes
- USB slot type
- USB type A
- Max USB current (A)
- 1.5
Other
- PCB temperature monitor
- Yes
- Voltage Monitor
- Yes
- Beeper
- Yes
Certification & Approvals
- Certification
- CE, FCC, IC, EAC, ROHS
- IP
- 00
